Marca: Gigabyte
Modelo: Z390 AORUS PRO WIFI (rev. 1.0)
Socket: Intel� Socket 1151
Chipset: Intel� Z390 Express
Soporte de Procesadores:
- Intel� de 9na y 8va generaci�n: Core� i9/Core� i7/Core� i5/Core� i3/Pentium�/Celeron�

Caracter�sticas Principales:
- Supports 9th and 8th Gen Intel� Core� Processors
- Dual Channel Non-ECC Unbuffered DDR4- 4 DIMMs
- Intel� Optane� Memory Ready
- 12+1 Phases Digital VRM Solution with DrMOS
- Advanced Thermal Design with Multi-cuts Heatsinks and Heatpipe
- Onboard Intel� CNVi 802.11ac 2x2 Wave 2 Wi-Fi
- ALC1220-VB Enhance 114dB(Rear) / 110dB(Front) SNR in Microphone with WIMA Audio Capacitors
- Intel� Gigabit LAN with cFosSpeed
- RGB FUSION 2.0 with Multi-Zone LED Light Show Design- Supports Addressable LED & RGB LED Strips
- Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
- Front USB 3.1 Gen 1 Type-C� Header
- Dual Ultra-Fast NVMe PCIe Gen3 x4 M.2 with Thermal Guards
- Multi-Way Graphics Support with Dual Armor and Ultra Durable� Design
- CEC 2019 Ready- Save Power With a Simple Click

Memoria:
4 x DDR4 DIMM- Max. 128GB (32GB single DIMM capacity)
Soporte para m�dulos de memoria DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz
Soporte para m�dulos de memoria ECC UDIMM 1Rx8/2Rx8 (operate in non-ECC mode)
Soporte para m�dulos de memoria non-ECC UDIMM 1Rx8/2Rx8/1Rx16
Arquitectura de memoria Dual Channel
Compatible con Intel� Extreme Memory Profile (XMP)

Gr�ficos:
Integrated Graphics Processor-Intel� HD Graphics support:
- 1 x HDMI port supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.2.
M�xima memoria compartida: 1 GB

Audio:
Realtek� ALC1220-VB codec
* The back panel line out jack supports DSD audio.
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out

LAN:
Intel� GbE LAN chip (10/100/1000 Mbit)

Wireless Communication module:
Intel� CNVi interface 802.11a/b/g/n/ac- supporting 2.4/5 GHz Dual-Band
BLUETOOTH 5
Support for 11ac 160 MHz wireless standard and up to 1.73 Gbps data rate
* Actual data rate may vary depending on environment and equipment.

Puertos de expansi�n:
- 1 x PCI Express x16 slot- running at x16 (PCIEX16)
* For optimum performance- if only one PCI Express graphics card is to be installed- be sure to install it in the PCIEX16 slot.
- 1 x PCI Express x16 slot- running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated- the PCIEX16 slot operates at up to x8 mode.
- 1 x PCI Express x16 slot- running at x4 (PCIEX4)
- 3 x PCI Express x1 slots
(Todos los slots PCI Express conforman el estandar PCI Express 3.0.)
- 1 x M.2 Socket 1 connector for an Intel� CNVi wireless module (CNVI)

Almacenamiento:
Chipset:
1 x M.2 connector (Socket 3- M key- type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A)
1 x M.2 connector (Socket 3- M key- type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2M)
6 x SATA 6Gb/s
Soporta Raid 0- 1- 5- 10
Intel� Optane� Memory Ready

Tecnolog�a Multi-Gr�ficos:
Soporte para AMD Quad-GPU CrossFire� y 3-Way/2-Way AMD CrossFire� technologies
Soporte para NVIDIA� Quad-GPU SLI� y 2-Way NVIDIA� SLI� technologies

USB:
Chipset:
1 x USB Type-C� port with USB 3.1 Gen 2 support on the back panel
1 x USB Type-C� port with USB 3.1 Gen 1 support- available through the internal USB header
2 x USB 3.1 Gen 2 Type-A ports (red) on the back panel
5 x USB 3.1 Gen 1 ports (3 ports on the back panel- 2 ports available through the internal USB header)
Chipset+ USB 2.0 Hub:
8 x USB 2.0/1.1 ports (4 ports on the back panel- 4 ports available through the internal USB headers)

Caracter�sticas Especiales:

Soporte para APP Center:
3D OSD
@BIOS
AutoGreen
Cloud Station
EasyTune
Easy RAID
Fast Boot
Game Boost
ON/OFF Charge
Platform Power Management
RGB Fusion
Smart Backup
Smart Keyboard
Smart TimeLock
Smart HUD
Smart Survey
System Information Viewer
USB Blocker
V-Tuner
Soporte para Q-Flash
Soporte para Xpress Install

Soporte Sistema Operativo:
Windows� 10 64-bit

Conectores:
4 x USB 2.0/1.1 ports
2 x SMA antenna connectors (2T2R)
1 x HDMI port
1 x USB Type-C� port- with USB 3.1 Gen 2 support
2 x USB 3.1 Gen 2 Type-A ports (red)
3 x USB 3.1 Gen 1 ports
1 x RJ-45 port
1 x optical S/PDIF Out connector
5 x audio jacks

Tama�o:
ATX Form Factor
30.5cm x 24.4cm

BIOS:
2 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
Support for DualBIOS�
PnP 1.0a- DMI 2.7- WfM 2.0- SM BIOS 2.7- ACPI 5.0
