Procesador
LGA1200 package:

11th Generation Intel� Core� i9 processors / Intel� Core� i7 processors / Intel� Core� i5 processors
10th Generation Intel� Core� i9 processors / Intel� Core� i7 processors / Intel� Core� i5 processors / Intel� Core� i3 processors/ Intel� Pentium� processors / Intel� Celeron� processors*
* Limited to processors with 4 MB Intel� Smart Cache- Intel� Celeron� G5xx5 family.
L3 cache varies with CPU

(Please refer to "CPU Support List" for more information.)
Chipset

Intel� B560 Express Chipset

Memoria

11th Generation Intel� Core� i9/i7/i5 processors:
Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz memory modules
10th Generation Intel� Core� i9/i7 processors:
Support for DDR4 2933/2666/2400/2133 MHz memory modules
10th Generation Intel� Core� i5/i3 /Pentium�/Celeron� processors:
Support for DDR4 2666/2400/2133 MHz memory modules
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules

(Please refer "Memory Support List" for more information.)
Gr�ficos Integrados
Integrated Graphics Processor-Intel� HD Graphics support:

1 x HDMI port- supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.3.
1 x DisplayPort- supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version- HDCP 2.3

(Graphics specifications may vary depending on CPU support.)
Audio

Realtek� Audio codec
High Definition Audio
2/4/5.1/7.1-channel

LAN

Realtek�2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)

Puertos de Expansi�n

1 x PCI Express x16 slot- running at x16 (PCIEX16)
* For optimum performance- if only one PCI Express graphics card is to be installed- be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 4.0 standard.)*
*Supported by 11th Generation processors only.
1 x PCI Express x16 slot- running at x4 (PCIEX4)
1 x PCI Express x1 slot
(The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)

Tecnolog�a Multi-Gr�ficos

Support for AMD Quad-GPU CrossFire� and 2-Way AMD CrossFire� technologies

Interfaz de Almacenamiento
CPU:

1 x M.2 connector (Socket 3- M key- type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2P_CPU)*
* Supported by 11th Generation processors only.

Chipset:

1 x M.2 connector (Socket 3- M key- type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SB)

6 x SATA 6Gb/s connectors
* Refer to "1-7 Internal Connectors-" for the installation notices for the M.2 and SATA connectors.
Intel� Optane� Memory Ready
USB
Chipset:

1 x USB Type-C� port on the back panel- with USB 3.2 Gen2 support
1 x USB 3.2 Gen2 Type-A ports (red) on the back panel
3 x USB 3.2 Gen1 ports (2 ports on the back panel- 1 port available through the internal USB header)
2 x USB 2.0/1.1 ports on the back panel

Chipset+USB 3.2 Gen 1 Hub:

1 x USB Type-C� port with USB 3.2 Gen1 support- available through the internal USB header
2 x USB 3.2 Gen1 ports available through the internal USB header

Chipset+ 2 USB 2.0 Hubs:

8 x USB 2.0/1.1 ports (4 ports on the back panel- 4 ports available through the internal USB headers)
